4. Exit the Serial Port Configuration mode: Press and release an output button.
C O N T R O L
PRESET
ENTER
I / O
VIDEO AUDIO
ESCVIEW
5
All Control and I/O buttons return
to unlit or background illumination.
Press and release
an output button.
Rear Panel Operations
The rear panel has a Reset button that initiates four levels of resets (numbered 1, 3, 4, and
5 for the sake of comparison with an Extron IPL product). The Reset button is recessed, so
use a small screwdriver, a pointed stylus, or a ballpoint pen. See the table on the next page
for a summary of the modes.
ATTENTION:
• Review the reset modes carefully. Some reset modes delete all user loaded content
and revert the device to default configuration.
• Étudier de près les différents modes de réinitialisation. Certains modes de
réinitialisation suppriment la totalité du contenu chargé de l’utilisateur et remettent
l’appareil en mode de configuration par défaut.
NOTE: The reset modes listed below close all open IP and Telnet connections and close
all sockets. Also, the following modes are separate functions, not a continuation from
Mode 1 to Mode 5.
Mode Activation Result Purpose and
Notes
1 Hold down the recessed Reset
button while applying power to the
matrix switcher.
NOTE: After a mode 1 reset is
performed, update the
matrix switcher firmware to
the latest version. Do not
operate the matrix switcher
firmware version that
results from the mode 1 reset.
If you want to use the factory
default firmware, you must
upload that version again (see
Firmware Upgrade Page
on page 132 for details on
uploading firmware).
The matrix switcher reverts to the factory
default firmware. Event scripting will not
start if the matrix switcher is powered on in
this mode. All user files and settings (such
as drivers, adjustments, and IP settings) are
maintained.
NOTE: If you do not want to update
firmware, or you performed a mode 1
reset by mistake, cycle power to the
matrix switcher to return to the firmware
version that was running before the
mode 1 reset. Use the 0Q SIS command
(see page 115) to confirm that the
factory default firmware is no longer
running (look for the asterisk [*] following
the version number.
Use mode 1
to revert to the
factory default
firmware version
if incompatibility
issues arise with
user-loaded
firmware.
3 Hold down the Reset button until
the Reset LED blinks once (about
3 seconds), then press and release
Reset (<1 second) within 1 second.
Mode 3 turns events on or off. During
resetting, the Reset LED blinks 2 times if
events are starting, 3 times if events are
stopping.
Mode 3 is
useful for
troubleshooting.
