XTP CrossPoint Series • Operation 63
4 Hold down the Reset button twice
(once at 3 seconds and again at 6
seconds). Then press and release
Reset (<1 second) within 1 second.
Mode 4:
• Enables ARP capability.
• Sets the IP address to the factory default.
• Sets the subnet address to the factory
default.
• Sets the gateway address to the factory
default.
• Sets port mapping to the factory default.
• Turns DHCP off.
• Turn events off.
The Reset LED blinks four times in quick
succession during the reset.
Mode 4 enables
you to set
IP address
information using
ARP and the
MAC address.
5 Hold down the Reset button until the
Reset LED blinks three times (once
at 3 seconds, again at 6 seconds,
and then again at 9 seconds). Then
press and release Reset (<1 second)
within 1 second.
Mode 5 performs a complete reset to
factory defaults (with the exception of the
firmware):
• Does everything mode 4 does.
• Resets most real time adjustments,
including:
• clears all ties and presets
• clears all mutes
• disables all RS-232 output inserts
• clears all audio settings
• Resets all IP options.
• Removes/clears all files for the matrix
switcher.
The reset LED blinks four times in quick
succession during the reset.
Mode 5 is useful
if you want to
start over with
configuration and
uploading or to
replace events.
