XTP CrossPoint Series • Programming Guide 115
Command Function
SIS Command
(Host to Unit)
Response
(Unit to Host)
Additional Description
Information requests
Information request
I
V
X4%
X
X4^
•A
X4%
X
X4^]
V (video) matrix size•A (audio) matrix size
Request part number
N
60-nnnn-nn
]
See the Extron Website for part numbers.
Request input/output board
configuration
*N
60-nnnn-nn.
X4&
1
X4&
2
...
X4&
n
X4*
1
X4*
2
...
X4*
n
]
Part number, dot, 4 or 8 (n)
X4&
s;
each is the input board installed, starting
from input slot 1, followed by 4 or 8 (n)
X4*
s; each is the output board installed.
NOTE: There are up to three separate sets of Extron firmware on which the matrix switcher can report: the controller firmware, which
is the overall control firmware; the Ethernet protocol firmware, which handles the Ethernet interface; and the latest optional Extron
firmware update, which is available at www.extron.com.
Query controller firmware version
Q
X4(]
Example:
Q
1.23
]
The factory-installed controller firmware
version is 1.23 (sample value only).
Query controller firmware version
(verbose)
0Q
X4(
-
X5)
-
X5)]
Detailed status of the controller firmware
and any firmware upgrade. The active
firmware is marked by an asterisk (*).
A caret (^) indicates a bad checksum
or an invalid load. ?.?? indicates that
firmware is not loaded.
Response description: Ethernet protocol firmware version-controller firmware version-updated firmware version
Example:
0q
See below
Ether
net protocol
firmware
Description
XTP II CrossPoint firmware version Updated firmware version
* indicates the version running Upload date and time
1.23-1.00(1.06-XTP CP Series -Tue, 02 Dec 2010 00:00:00 GMT)-1.00*(1.06-XTP CP Series -Mon, 02 Apr 2012 16:39:21 GMT)
NOTE:
X4%
= Number of inputs 4, 8, 12, 16, 20, 24, 28, or 32
X4^
= Number of outputs 4, 8, 12, 16, 20, 24, 28, or 32
X4&
= Installed input board A = XTP CP 4i 4K (TP) K = XTP CP 4i HDMI DMA
F = XTP CP 4i VGA N = XTP CP 4i Fiber 4K
G = XTP CP 4i (TP) P = XTP CP 4i 3G-SDI
H = XTP CP 4i HDMI T = XTP CP 4i HD 4K PLUS
I = XTP CP 4i DVI Pro X = No board installed
X4*
= Installed output board B = XTP CP 4o 4K (TP) M = XTP CP 4o SA (stereo audio)
D = XTP CP 4o (TP) O = XTP CP 4o Fiber 4K
E = XTP CP 4o HDMI U = XTP CP 4o HD 4K PLUS
J = XTP CP 4o DVI Pro X = No board installed
X4(
= Firmware version number to second decimal place (x.xx)
X5)
= Verbose firmware version-description-upload date/time (see the Query firmware version (verbose) command, above.
