XTP CrossPoint Series • Programming Guide 116
Command Function
SIS Command
(Host to Unit)
Response
(Unit to Host)
Additional Description
Information requests (continued)
Request system status
S
See below
XTP CrossPoint 3200:
X5!
•
X5!
•
X5!
•
X5!
•
X5!
•
X5@
•
X5#
•
X5#
•
X5#
•
X5#
•
X5#
•
X5#
•
X5#
•
X5$X5$X5$X5$]
XTP CrossPoint 1600 (no redundant power supply):
X5!
•
X5!
•
X5!
•
X5@
•
X5#
•
X5#
•
X5$X5$]
XTP CrossPoint 1600 (redundant power supply):
X5!
•
X5!
•
X5!
•
X5!
•
X5!
•
X5@
•
X5#
•
X5#
•
X5$X5$X5$X5$]
Response description (XTP CrossPoint 3200):
PS1 (12 V)•PS2 (12 V)•PS3 (12 V)•PS4 (48 V)•3.3 V•°F•Fan 1 RPM (F1)•F2•F3•F4•F5•F6•F7•PS status 1 (PS1) PS2 PS3 PS4
]
Response description (XTP CrossPoint 1600, without optional redundant power supply):
PS1 (12 V)•PS2 (48 V)•3.3 V•temp. (°F)•Fan 1 speed (F1)•F2•PS status 1 (PS1) PS2
]
Response description (XTP CrossPoint 1600, with optional redundant power supply):
PS1 (12 V)•PS2 (48 V)•PS3 (12 V)•PS4 (48 V)•3.3 V•°F•Fan 1 speed (F1)•F2•PS status 1 (PS1) PS2 PS3 PS4
]
NOTE:
• If a primary power supply that is not backed up by a redundant supply fails, return the matrix switcher to Extron for immediate
repairs.
• If a backed up power supply, a redundant power supply, or a cooling fan fails, return the matrix switcher at your earliest
opportunity.
Example
(XTP CrossPoint 3200):
S
See below
Fan 2 rotating at 888 RPM12V power supply 1 at 12.01V
Temperature is 73.4 °F
All 4 power supplies installed
12.01
�11.31�11.31�48.00�+3.30�+73.40�00892�00888�00892�01061�01022�00892�00888�1111
View all input connections
0LS
X%
1
X%
2
X%
3
...
X%
n
]
16 or 32 (
n
)
X%
s; each is the connection
status of an input, starting from input 1.
Example
(XTP CrossPoint 3200):
0LS
Input:
Response Status:
No input detected
Sync detected Sync detected
1 2345
6
7 8 9
1011
12
13
32
0 0 0 1 1 1 0 1 0 0 1 0 1. . .0
NOTE: X% = Input signal status 0 = No signal detected 1 = Signal detected
X5! = Voltage Positive or negative voltage and magnitude
X5@ = Internal temperature Degrees Fahrenheit
X5# = Fan speed RPM
X5$ = Power supply installation status 0 = No power supply installed 1 = Power supply installed
Symbol definitions for IP and Remote port specific SIS commands
X6!
= Matrix name Up to 24 alphanumeric characters
NOTE: The HTML language reserves certain characters for specific functions
(see Special Characters on page 120).
X6@
=
Default name XTP-CP-nn00 + Last 3 pairs of MAC address.
nn = 16 or 32.
X6#
=
Time and date (for set)
In the format: MM/DD/YY
•
HH:mm:SS where:
MM = month: 01 (January) to 12 (December)
DD = day: 01 to 31
YY = year: 00 to 99
HH = hour: 00 to 23
mm = minute: 00 to 59
SS = second: 00 to 59
