XTP CrossPoint Series • Programming Guide 108
Command Function
SIS Command
(Host to Unit to Endpoint)
Response
(Endpoint to Unit to Host)
Additional Description
XTP R HDMI, XTP R HD 4K, and XTP FR HD 4K receiver commands (continued)
HDCP status
View output HDCP status
E
O
X@
HDCP
} X3%]
View HDCP status of all outputs
E
OHDCP
} X3%
1
X3%
2
X3%
3
...
X3%
n
]
n = either 16 or 32
Relay controls
Turn on an endpoint relay
EX@
*
X3(
*1RELY
}
Rely
X@
*
X3(
*1
]
Turn on relay
X3(
in output
X@
.
Turn off an endpoint relay
EX@
*
X3(
*0RELY
}
Rely
X@
*
X3(
*0
]
Turn off relay
X3(
in output
X@
.
Toggle an endpoint relay
EX@
*
X3(
*2RELY
}
Rely
X@
*
X3(
*
X4!]
Toggle (on-to-off or off-to-on) relay
X3(
in output
X@
.
Pulse an endpoint relay
EX@
*
X3(
*3*
X4)
RELY
}
Rely
X@
*
X3(
*3
]
Turn on relay
X3(
in output
X@
for an
interval defined as
X4)
. Each step of
X4)
is 16 ms.
Example:
E
1*2*3*45RELY
}
Rely1*2*3
]
Turn on relay 2 in output endpoint 1 for
720 ms
(0.72 sec,
X4)
= 45 * 16 ms = 720 ms).
View an endpoint relay status
EX@
*
X3(
RELY
} X4!]
On or off.
View video and audio mutes
View output mutes
E
VM
} X3*
1
X3*
2
...
X3*
n
]
Each
X3*
response is the mute status of
an output, starting from output 1.
n = either 16 or 32.
Example :
(XTP CrossPoint 3200)
E
VM
}
Digital audio is muted on outputs 2 and
3, video on output 5, and video and
digital audio on output 26. All other
outputs are unmuted.
02201000000000000000000003000000
]
XTP SR HDMI, XTP SR HD 4K, and XTP SFR HD 4K scaler commands
Video mutes
Video mute
X@
*1B Vmt
X@
*1
]
Mute output
X@
video (video off).
Video unmute
X@
*0B Vmt
X@
*0
]
Unmute output
X@
video (video on).
Read video mute
X@
B
X2@] X2@
= 1 = enable (muted)
0 = disable (unmuted) (default).
Global video mute
1*B
Vmt1
]
Mute all video outputs.
Global video unmute
0*B
Vmt0
]
Unmute all video outputs.
NOTE: X@ = Output number 01 – 16 or 32
X2@ = Enable and disable for mutes 0 = Disable 1 = Enable
X3% = HDCP status (for outputs) 0, 2, 4, or 6 = No monitor connected
1, 3, or 5 = Monitor connected but the video signal is not encrypted
7 = Monitor connected and the video signal is encrypted
X3&
=
Digital and analog audio mute status 0 = No mutes 2 = Analog audio mute
1 = Digital audio mute 3 = Digital and analog audio mute
X3* = Video and audio mute status 0 = No mutes 4 = Analog audio mute
1 = Video mute 5 = Video and analog audio mute
2 = Digital audio mute 6 = Digital and analog audio mute
3 = Video and digital audio mute 7 = Video, digital audio, and analog audio mute
X3(
= Relay on endpoint 1 or 2
X4)
= Pulse duration 0 through 65535 (each step = 16 ms, see the example above)
X4!
= Relay status
0
= Off
1
= On
