XTP CrossPoint Series • Programming Guide 84
X1%
=
Port number 01 = remote RS-232/RS-422 port
02 = unused
X1^
=
Baud rate 300, 600, 1200, 1800, 2400, 3600, 4800, 7200,
9600, 14400, 19200, 28800, 38400, 57600, 115200
X1&
=
Parity O = odd
E = even
N = none (default)
M = mark
S = space
X1*
=
Data bits 7, 8 (default)
X1(
=
Stop bits 1 (default), 2
X2)
=
Port timeout interval (in 10
second increments)
1 (10 seconds) to 65000
30 = 300 seconds or 5 minutes (default)
NOTE: X1% through X2) are repeated on page 118 as X7( through X8# and
X9@.
X2!
=
UART starting point
The starting point (X2!) is the front panel
RS-232/RS-422 port.
The next position (X2!
+1
) is not used.
X2!
+2
to X2!
+17
= inputs (XTP CrossPoint 1600)
X2!
+2
to X2!
+33
= inputs (XTP CrossPoint 3200)
X2!
+33
to X2!
+48
= outputs (XTP CrossPoint 1600)
X2!
+34
to X2!
+85
= outputs (XTP CrossPoint 3200)
Default values:
1999 = rear panel remote RS-232/RS-422 port
2000 = unused
2001 to 2016 = XTP CrossPoint 1600 inputs
2001 to 2032 = XTP CrossPoint 3200 inputs
2033 to 2048 = XTP CrossPoint 1600 outputs
2033 to 2064 = XTP CrossPoint 3200 outputs
X2@
=
Enable or disable 0 = disable
1 = enable
X2#
=
Amount of power requested 00 or 13 (watts)
X2$
=
Power status 0 = unpowered endpoint
1 = power provided to endpoint
2 = power available but disabled
3 = no power available, but enabled
4 = fault
X2%
=
Wattage Power usage in 0.1 watt increments.
Example: 260 = 26.0 watts.
X2^
=
Power supply status 0 = ok
1 = no ok
X2&
=
AESC digital channel pair 1 (default) or 2
X2*
=
AESG digital channel group 1 (default) or 2
X2(
=
Input video source 0 = auto
1 = video
2 = s-video
3 = RGBcvS (SCART)
4 = YUV interlace
5 = RGB
6 = YUV
