XTP CrossPoint Series • Programming Guide 85
X3)
=
Detected video format 0 = no signal detected
1 = video
2 = s-video
3 = RGBcvS (SCART)
4 = YUV interlace
5 = RGB
6 = YUV
X3!
=
Picture adjustments 000 to 255 (128 = default)
X3@
=
Shift 0 to 65535
X3#
=
Analog input preset 0 through 8
X3$
=
Output audio source 0 = original HDMI audio
1 = embed audio
X3%
=
HDCP status (for outputs) 0, 2, 4, or 6 = no monitor connected
1, 3, or 5 = monitor connected but the video signal
is not encrypted
7 = monitor connected and the video signal is
encrypted
X3^
=
Volume adjustment range 00 through 64 (1 dB per step except for 0 to 1,
which is 13 dB) (see the table on page 104)
X3&
=
Digital and analog audio
mute status
0 = no mutes (default)
1 = digital audio mute
2 = analog audio mute
3 = analog and digital audio mute
X3*
=
Video and audio mute
status
0 = no mutes (default)
1 = video mute
2 = digital audio mute
3 = video and digital audio mute
4 = analog audio mute
5 = video and analog audio mute
6 = digital and analog audio mute
7 = video, digital audio, and analog audio mute
X3(
=
Relay on endpoint 1 or 2
X4)
=
Pulse duration 0 to 65535 (each step = 16 ms, see the Example
on page 108)
X4!
=
Relay status 0 = off
1 = on
X4@
=
Test pattern 00 = disable (default)
01 = color bars, 720p @ 50 Hz
02 = black field, 720p @ 50 Hz
03 = color bars, 720p @ 60 Hz
04 = black field, 720p @ 60 Hz
05 = color bars, 1080p @ 60 Hz
06 = black field, 1080p @ 60 Hz
07 = color bars and audio, 720p @ 50 Hz
08 = black field and audio, 720p @ 50 Hz
09 = color bars and audio, 720p @ 60 Hz
10 = black field and audio, 720p @ 60 Hz
11 = color bars and audio, 1080p @ 60 Hz
12 = black field and audio, 1080p @ 60 Hz
