XTP CrossPoint Series • Programming Guide 86
X4#
=
Name 12 characters maximum
NOTE: The HTML language reserves certain characters for specific functions
(see Special Characters on page 120).
X4$
=
Lock mode 0 = mode 0
1 = mode 1
2 = mode 2 (default)
X4%
=
Number of inputs 4, 8, 12, 16, 20, 24, 28, or 32
X4^
=
Number of outputs 4, 8, 12, 16, 20, 24, 28, or 32
X4&
=
Installed input board A = XTP CP 4i 4K (TP)
F = XTP CP 4i VGA
G = XTP CP 4i (TP)
H = XTP CP 4i HDMI
I = XTP CP 4i DVI Pro
K = XTP CP 4i HDMI DMA
N = XTP CP 4i Fiber 4K
P = XTP CP 4i 3G-SDI
T = XTP CP 4i HD 4K PLUS
X = no board installed
X4*
=
Installed output board B = XTP CP 4o 4K (TP)
D = XTP CP 4o (TP)
E = XTP CP 4o HDMI
J = XTP CP 4o DVI Pro
M = XTP CP 4o SA (stereo audio)
O = XTP CP 4o Fiber 4K
U = XTP CP 4o HD 4K PLUS
X = no board installed
X4(
=
Firmware version number to second decimal place (x.xx)
X5)
=
Verbose firmware version-description-upload date/time (see Query firmware
version (verbose) command on page 115)
X5!
=
Voltage Positive or negative voltage and magnitude
X5@
=
Internal temperature Degrees Fahrenheit
X5#
=
Fan speed in RPM
X5$
=
Power supply installed
status
0 = no power supply installed
1 = power supply installed
X5%
=
Transmitter endpoint input 1 to 2 or 1 to 3 depending on the transmitter
