XTP CrossPoint Series • HTML Operation 141
Number
of Steps
dB of
Attenuation
Output
Volume
Number
of Steps
dB of
Attenuation
Output
Volume
Number
of Steps
dB of
Attenuation
Output
Volume
00 76 0% 22 42 37% 44 20 70%
01 63 5.5% 23 41 38.5% 45 19 71.5%
02 62 7% 24 40 40% 46 18 73%
03 61 8.5% 25 39 41.5% 47 17 74.5%
04 60 10% 26 38 43% 48 16 76%
05 59 11.5% 27 37 44.5% 49 15 77.5%
06 58 13% 28 36 46% 50 14 79%
07 57 14.5% 29 35 47.5% 51 13 80.5%
08 56 16% 30 34 49% 52 12 82%
09 55 17.5% 31 33 50.5% 53 11 83.5%
10 54 19% 32 32 52% 54 10 85%
11 53 20.5% 33 31 53.5% 55 9 86.5%
12 52 22% 34 30 55% 56 8 88%
13 51 23.5% 35 29 56.5% 57 7 89.5%
14 50 25% 36 28 58% 58 6 91%
15 49 26.5% 37 27 59.5% 59 5 92.5%
16 48 28% 38 26 61% 60 4 94%
17 47 29.5% 39 25 62.5% 61 3 95.5%
18 46 31% 40 24 64% 62 2 97%
19 45 32.5% 41 23 65.5% 63 1 98.5%
20 44 34% 42 22 67% 64 0 100%
21 43 35.5% 43 21 68.5%
Muting and unmuting an audio output
Mute and unmute a video output, audio output, or both as follows:
1. Click either the Video, Audio, or Video & Audio
button to select the output signal stream to mute.
2. To mute and unmute an output, click the A/V Mute button associated with
an output. Each click toggles the mute status.
3. To mute or unmute all outputs, click the Mute All or Unmute
All button, as desired.
