XTP CrossPoint Series • Installation 28
B
Power LEDs —
NOTES:
• The XTP CrossPoint 3200 has four power supplies installed. These power
supplies are indicated by the following LEDs:
• LEDs 1 and 2 — Indicate the status of the two primary 12 V supplies.
• LED 3 — Indicates the status of the redundant 12 V supply.
• LED 4 — Indicates the status of the 48 V power supply, which provides PoX.
• The XTP CrossPoint 1600 has two power supplies, which provide 12 V and
48 V in its standard configuration, with two optional, redundant second power
supplies available. These power supplies are indicated by the following LEDs:
• Primary LED 1 — Indicates the status from the standard primary 12 V
supply.
• Redundant LED 1 — Indicates the status of 12 V from the optional
redundant supply.
• Primary LED 2 — Indicates the status from the standard primary 48 V
supply, which provides PoX.
• Redundant LED 2 — Indicates the status of 48 V from the optional
redundant supply.
Green — Indicates that the associated power supply is operating within normal
tolerances.
Red — Indicates that the associated power supply is operating outside the normal
tolerances or has failed.
