XTP CrossPoint Series • Programming Guide 90
X$
Source or value
X$
Source or value
X$
Source or value
X$
Source or value
X$
Source or value
3200 1600 3200 1600 3200 1600 3200 1600 3200 1600
HDMI – PC values, all with 2-channel embedded audio
093 077
1024x768 @ 50 Hz
099 083
1280x1024 @ 50 Hz
105 089
1400x1050 @ 50 Hz
111 095
1600x1200 @ 50 Hz
117 101
2048x1080 @ 50 Hz
094 078
1024x768 @ 60 Hz
100 084
1280x1024 @ 60 Hz
106 090
1400x1050 @ 60 Hz
112 096
1600x1200 @ 60 Hz
118 102
2048x1080 @ 60 Hz
095 079
1280x768 @ 50 Hz
101 085
1360x768 @ 50 Hz
107 091
1440x900 @ 50 Hz
113 097
1680x1050 @ 50 Hz
096 080
1280x768 @ 60 Hz
102 086
1360x768 @ 60 Hz
108 092
1440x900 @ 60 Hz
114 098
1680x1050 @ 60 Hz
097 081
1280x800 @ 50 Hz
103 087
1366x768 @ 50 Hz
109 093
1600x900 @ 50 Hz
115 099
1920x1200 @ 50 Hz
098 082
1280x800 @ 60 Hz
104 088
1366x768 @ 60 Hz
110 094
1600x900 @ 60 Hz
116 100
1920x1200 @ 60 Hz
HDMI – HDTV values
119 103
480p @ 60 Hz 2-channel audio
122
*
106
*
720p @ 60 Hz 2-channel audio
125 109
1080i @ 50 Hz 2-channel audio
128 112
1080i @ 60 Hz multi-channel audio
131 115
1080p @ 50 Hz multi-channel audio
120 104
576p @ 50 Hz 2-channel audio
123 107
720p @ 50 Hz multi-channel audio
126 110
1080i @ 60 Hz 2-channel audio
129 113
1080p@ 50 Hz 2-channel audio
132 116
1080p @ 60 Hz multi-channel audio
121 105
720p @ 50 Hz 2-channel audio
124 108
720p @ 60 Hz multi-channel audio
127 111
1080i @ 50 Hz multi-channel audio
130 114
1080p @ 60 Hz 2-channel audio
User – Assigned EDIDs
133 117
User assigned 1
135 119
User assigned 3
137 121
User assigned 5
139 123
User assigned 7
134 118
User assigned 2
136 120
User assigned 4
138 122
User assigned 6
140 124
User assigned 8
*
Default value, digital
