RESTRICTED USE ONLY Fargo Electronics, Inc.

DTC400 Card Printer/Encoder User Guide (Rev. 2.2)

4-44

Resolving the Incorrect Image Darkness problems (continued)

Step Procedure

Correct the Image Darkness. See the Using the Image Darkness Option

procedure.
