RESTRICTED USE ONLY Fargo Electronics, Inc.

DTC400 Card Printer/Encoder User Guide (Rev. 2.2)

11-11

Downloading Firmware (continued)

Step Procedure

9 From the computer’s desktop, double click on the Firmware .exe file to un-zip it,

as shown below.
