RESTRICTED USE ONLY Fargo Electronics, Inc.

DTC400 Card Printer/Encoder User Guide (Rev. 2.2)

11-12

Downloading Firmware (continued)

Step Procedure

Click on the Browse button on the WinZip Self-Extractor window, as shown

below.
