RESTRICTED USE ONLY Fargo Electronics, Inc.

DTC400 Card Printer/Encoder User Guide (Rev. 2.2)

11-13

Downloading Firmware (continued)

Step Procedure

Select the Desktop, then click on the OK button in the Browse for Folder dialog,

as shown below.
