Chapter 7: Controller Software
Factory Predefined Scan Profiles Overview
Indoor...10 m Indoor 10 m...
Outdoor...
20 m
Outdoor
20 m...
Preview Object HD
Description
Scan indoors
where the dis-
tances from the
scanner to the
main objects of
interests are
less than 10 m
Scan indoors
where the dis-
tances from the
scanner to the
main objects of
interests are
greater than
10 m
Scan outdoors
where the dis-
tances from
the scanner to
the main
objects of inter-
ests are less
than 20 m
Scan outdoors
where the dis-
tances from the
scanner to the
main objects of
interests are
greater than
20 m
Capture a fast
and rough pre-
view scan of
the environ-
ment in low res-
olution.
Scan certain
objects or areas in
very high resolu-
tion. It is recom-
mended to limit the
scan area to the
object or area of
interest, else the
scan might take
very long to com-
plete.
Quality
3x 4x 4x 4x 4x 6x
Vertical
Area
-60° - 90° -60° - 90° -60° - 90° -60° - 90° -60° - 90° -60° - 90°
Hor. Area
0° - 360° 0° - 360° 0° - 360° 0° - 360° 0° - 360° 0° - 360°
Inclinometer
ON ON ON ON ON ON
Compass
ON ON ON ON ON ON
Altimeter
ON ON ON ON ON ON
Use GPS
OFF OFF ON ON ON ON
Color
ON ON ON ON OFF ON
Clear
Contour
ON ON ON ON ON ON
Clear Sky
ON ON ON ON ON ON
Distance
Range
Near Near Normal Far
Distances
Normal Near
The following values refer to full area scans (360° horizontally / 300° vertically):
Resolution
(MPts)
11 28.2 28.2 44 2.8 176.0
Net Scan
Duration
(hh:mm:ss)
00:05:11 00:08:52 00:08:52 00:09:12 00:01:27 01:58:49
Scan File
Size (mb)
190.70 243.88 243.88 171.18 8.53 2338.20
Scan Size
(Pt)
5156 x 2134 8248 x 3414 8248 x 3414 10310 x 4268 2578 x 1068 20622 x 17066
