KT5500 5-
1
/
2
” Tong & CLInCHER® BaCKup
SECTIon ConTEnTS
7.34
TECHnICaL ManuaL
HyDRauLIC VaLVE InfoRMaTIon
Control Adjustment Range
Material/Seal
Material
L Standard S crew Adjustment A 100 - 3000 psi
(7 - 210 bar),
1000 psi (70
bar) Standard
Setting
W 150 - 4500 psi
(10,5 - 315
bar), 1000 psi
(70 bar)
Standard
Setting
N Buna-N
Standard Options
J Capped Screw Adjustment
K Handkn ob
O Handknob with Panel Mount
F Hex Head Screw with
Locknut
W* Max. Setting Limiter
3* Non Adjustable, Fixed
Setting
C* Tamper Resistant - Factory
Set
C 150 - 6000 psi
(10,5 - 420 bar),
1000 psi (70
bar) Standard
Setting
E 25 - 400 psi (1,7
- 28
bar), 200
psi (14 bar)
Standard Setti
ng
D 25 - 800 psi (1,7
- 55 bar), 400
psi (30 bar)
Standard Setting
B 50 - 1500 psi
(3,5 - 105 bar),
1000 psi (70
bar) Standard
Setting
Q 60 - 400 psi (4 -
25 bar), 200 psi
(14 bar)
Standard Setting
N 60 - 800 psi (4 -
55 bar), 400 psi
(30 bar)
Standard Setting
P Stainless/Buna-
N
W Stainless/Viton
V Viton
*Special Setting required, specify at time of order
Related Information :
Explanation of Sun cartridge control options - US units.
Explanation of Sun cartridge control options - metric units.
Two-piece, floating cartridge construction.
Copyrigh t © 2003 Sun Hydraulics Corporation .
All rights r eserved.
Terms and Conditions - Statement of Privacy
Technical Data
U.S. Units Metric Units
Cavity
T-3A
Capacity
50 gpm 200 L/min.
Adjustment - Number of Clockwise Turns to
Increase Setting
5 5
Factory Pressure Settings Established at
4 gpm 15 L/min.
Maximum Operating Pressure
5000 psi 350 bar
Maximum Valve Leakage at 110 SUS (24 cSt)
3 in³/min.@1000 psi 50 cc/min.@70 bar
Response Time - Typical
10 ms 10 ms
Series (from Cavity)
2
Valve Hex Size
1 1/8 in. 28,6 mm
Valve Installation Torque
45 - 50 lbf ft 60 - 70 Nm
Adjustment Screw Hex Socket Size
5/32 in. 4 mm
Adjustment Nut Hex Size
9/16 in. 15 mm
Adjustment Nut Torque
108 lbf in. 12 Nm
Model Weight
.50 lb 0,25 kg
Seal Kits
Viton: 990-203-006
Seal Kits
Buna: 990-203-007
Option Selection
RPGC-L A N
