Mechanical Assembly Procedure (Continued):
83. Attachtheoutletcouplingsupportweldment(PN101-0023)totheweldmentmountusingtwo3/8”NCx1”hexboltsand
3/8”lockwashers.Attachtheadjustmentplate(PN101-0277)totheoutletsupportweldmentusingfour3/8”NCx1”hex
bolts,3/8”narrowflatwashers,and3/8”UNChexnylocknuts.
84. Coatthethreadsofthehydraulicvalvemountingposts(PN101-0116)withLoctiteandthreadintothetopplatejustbehind
thebrakebandoneithersideofthebrakebandretainer.
85. MounttheDVA35hydraulicvalveassemblyonthemountingpostsusingtwo1/2”UNCx4-1/2”hexboltsand1/2”narrow
flatwashers.
