Setting procedures: -
1. Press [Unit] or [MR] to select the preferred parameter.
2. Then [Print/M+] to save and continue with Action on Negative Value setting. 2 parameters are available: -
• On = Check function applies also to negative results.
• Off = Check function does not apply to negative results.
3. Then [Print/M+] to save and return to F15.
Communication
Ports Setting
5 UARTs (UART 0 ~ 4) and 1 Lan port are available. Refer to the operation manual for more setting details.
Machine ID and
Group Number
Notes: -
• Machine ID number is also used as the address number of this instrument for RS485 communication.
• When machine ID is = blank, this instrument does not have any address number in the RS485 network.
• Each machine should have a unique machine ID number in a multi-instrument application with the same RS485 network.
• Group number can be used as production line number in a multi-instrument application.
• The machine ID and group number inputted will be carried out on printout formats Lab 3 ~ Lab 5.
Setting procedures: -
1. Go to F18 and press [Print/M+].
2. Input Machine ID number (00 ~ 98) and press [Print/M+]. To clear machine ID number, press [CE/x10] and press [Print/M+] to save.
3. Input group number (00 ~ 99) and press [Print/M+]. To clear the group number, press [CE/x10] and press [Print/M+] to save and return
to F18.
Manual Entry for
Customer/Product
Code & Description
P Code
(Product Code & Description)
C Code
(Customer Code & Description)
• Customer & Product code accept both numeric numbers and alphabets. Maximum length = 18 digits (; * # not accepted).
• Customer & Product Description accept both numeric numbers and alphabets. Maximum length = 30 digits (; * # not accepted).
• To allow letters and symbols entry via keyboard, set F30 to Yes.
Notes: -
a. If a Product/Customer Code is = blank, Product/Customer Description will be ignored.
b. Customer and Product code does not support print format 1 (Lab 1).
c. Customer and product code inputted will be sent to output formats Lab 2 ~ Lab 5.
