Chapter 5: System Software
5-11
‡ Known Chain Pitch & Teeth Present/Not Present Present
‡ Encoder Resolution 500/5000 Pulse 500 Pulse
‡ Save Default Constants Execute
∞ Conveyor Segment Pitch 50-700 (1/10th) mm 381 mm
∞ Teeth/Conveyor Segment 1-3 Teeth 2 Teeth
∞ Calibrate Encoder Execute
∞ Calibrate Encoder Value Pulses/10m Pulses/10m
∞ Encoder Prescaler Value 2- 50 Pulses 5 Pulses
∞ Gamma Sample Cutoff Limit 1-50 Samples 4 Samples
∞ Gamma Samples Per Encoder 1-50 Samples
Diagnostics Key 6
* System Diagnostic Error 0-69
Function Group Function Name Parameter Default
?
6
Industrial Dynamics Company, Ltd. Document 40255-0600
