Filtec FT-50c - Filtec Model FT-50 Radiation Exposure Profiles

Radiological Safety
XVII
Filtec Model FT-50 Radiation Exposure Profiles
Figure 2. FT-50 Radiation Profile Schematic: Gamma Guage: 100 or 300 mCi Source.
1
5
2
3
4
6
8
7
4" - 7.5"
6
1
3
7
4
No. Description No. Description
1 Inspection Head 5 Radiation Detector
2 Inspection Tunnel 6 Limits of Main Beam
3 5 cm Isodistance Contour 7 Detector Window
4 Sealed Americium-241 8 Shielding Bar (1/4” Thick Steel)
Industrial Dynamics Company, Ltd. Document 40255-0600
