Chapter 5: System Software
5-41
Diagnostics Function Group
Displays the current diagnostic error. Clearing the error stops the
warning beacon from flashing and the Remote Alarm PLC output
signal.
How to Access Diagnostic Error Codes
Note
Do not use the Reset Switch to clear diagnostic errors.
To view the error:
1. Press Key 6 to display the current diagnostic error number.
2. Press the Arrow Key to scroll through the error definition.
3. When you reach the end of the message, press the Arrow Key
once again to clear the error.
Industrial Dynamics Company, Ltd. Document 40255-0600
