FT-50 Fill Level Inspector Service Manual
10-4
Switch Function Configurations
The default configuration for each option is indicated in bold. The
following table represents the standard FT-50 configuration.
Depending upon the options installed in your FT-50 the default
configuration may be different. Refer to the System Configuration
Sheet located inside the cover of your FT-50 for you specific factory
configuration.
Switch Function Open = 1 Closed = 0
Switch Pack S1
S1-1 Inspection Logic Overfill Underfill
S1-2 Software Protect On Off
S1-3 Speed Tracking Variable Fixed
S1-4 Languages Second English
S1-5 System Configuration On Off
S1-6 Not Used NA NA
S1-7 Not Used NA NA
S1-8 Password Required Not Required
Switch Pack S2
S2-1 Baud Rate 1200 9600
S2-2 Handshake Flags On Off
S2-3 Parity On/Off On Off
S2-4 Parity Odd/Even Even Odd
S2-5 Character Size 7 Bit 8 Bit
S2-6 Multi-Serial RS-485 RS-232/422
S2-7 Led Section Selector Section 2 Section 1
S2-8 Led Bank Selector Bank 2 Bank 1
Slide Switches Position A Position C
S3 RS-232/RS422 RS-232 RS-422/485
S11 Save Setup Enable Disable
S13 Auto Reset Disabled Enabled
