Chapter 8: Diagnostic and Repair Procedures
8-17
Processing System Troubleshooting
Main Processor Card
If the Main Processor Card fails a total system shutdown will
occur. Check to be sure that all power sources are functioning
correctly. If they are functioning correctly, replace the processor
card.
Figure8-2. The Processor Card.
LED 12
U25
U26
Industrial Dynamics Company, Ltd. Document 40255-0600
