FireClass FC501 - DEVICE MAPPING Phase

Ø
The output channels of the modules, sounders and
beacons will be set to active on the alarm of the assi
-
gned zone.
3-DEVICE MAPPING
The third and last phase is activated on demand at the
end of the Auto-addressing phase.
This phase allows:
Ø
Locate the positioning in the system of all the devices
through their activation (in the case of output modu
-
les only, sounders or beacons, they will be suitably
activated by the panel ( see Figure 57, 3A).
Ø
Carry out a preliminary test of the system.
Ø
Program the most important parameters of each lo
-
cated device.
Ø
Automatically assign labels to all devices.
Ø
Assign automatically the zones based on assigned
address to each device.
Ø
Automatically configure the output channels of the
modules, sounders and beacons to activate on the
alarm of the assigned zone.
The third phase represents a powerful and flexible tool
that allows to "draw" the plant being in front of the panel
and without the use of a PC and its SW configuration.
A series of controls have been designed to prevent the
generation of incorrect or not manageable conditions.
For each device to locate occurs that:
Ø
The address to be assigned does not belong to an ol
-
der generation device (FC400 series).
Ø
The address to be assigned is in the range from 1 to
128.
Ø
The address to be assigned belongs to a new gene
-
ration device and that device is present in the list of
devices to locate.
Ø
The address to be assigned is not among those assi
-
gned automatically.
QUICK START-UP PROCEDURE 59
LOOP PANEL
MESSAGE
Differences found!
Automatic zones
assignment
Not addressed devices
found
start autoaddressing ?
1
All devices not
addressed
DEFAULT
*
2
Some devices
addressed
+
Some devices not
addressed
DEFAULT
(Applicable only to the
already addressed
devices)
*
*
3
All devices
addressed
DEFAULT
*
4
Fully addressed
Same configuration
CONFIGURED
5
Fully addressed
Different
configuration
CONFIGURED
*
New
configuration
(Applicable only to all
already
addressed devices)
*
Add
devices
(Applicable only to new
already addressed
devices)
*
6
Same configuration
+
Not addressed
devices
CONFIGURED
*
7
Different
configuration (*)
+
Not addressed
devices
CONFIGURED
*
New
configuration
(Applicable only to all
already
addressed devices)
*
*
Add
devices
(Applicable only to the
new
already addressed
devices)
*
*
Figure 58 The table shows the kind of messages, and relevant action required during the enroll process in function of the
loop and panel configuration. Note (*) indicates that the message is displayed and relevant action is executed
