DMP30 / DMP40
Technical Data
Connectable probes
Digital probes with USB-C female jack, probe names always beginning with the
letter D
Via DMP-F-Probe-Adapter many analog probes with 10-pin male jack; probe
names beginning with the letter F or containing the letter F;
Probes connectable to the DMP-F-Probe-Adapter: F20H, FA100, FA14, FA30,
FA70, FA9, FAW3.3, FD10, FD13H, FGA0.6H FGAB1.3, FGAB1.3T, FGABW1.3,
FGB2, FGBW2, FKB10, FKB4, FTA2.4-MC, FTA2.4-SC, FTA3.3, FTA3.3-5.6,
FTA3.3-5.6-HF, FTA3.3F-Cr, FTA3.3FG, FTA3.3H, FTD3.3, V7FKB4
Not supported probes: duplex probes (FDX10, FDX13H, FN4D) and special
probes for special customer-specific applications
The Fischer probe program encompasses nearly 100 probes designed to ensure
optimal results with highest accuracy for the widest range of measurement ap-
plications. At factory each individual probe is adjusted at several reference points
with the greatest care to ensure the highest possible degree of trueness.
Energy management
Power supply: Li-Ion rechargeable battery, model RRC1130
Nominal voltage: 3.8 V=
Nominal capacity: 3880 mA, 14.7 Wh
max. charge voltage: 4.35 V=
max. charge current: 2.4 A
DELTASCOPE
DMP30
ISOSCOPE
DMP30
DUALSCOPE
DMP40
SR-SCOPE
DMP30
Test methods
DIN EN ISO 2178 / ASTM D7091
Magnetic induction test method,
measurement of non-magnetic coat-
ings on magnetic substrates
DIN EN ISO 2360 / ASTM D7091
Amplitude-sensitive eddy current
test method, measurement of non-
conductive coatings on non-magnet-
ic substrate metals
