86
Batch settings DMP30 / DMP40
2. Have you selected the Statistics Measurement view?
• Yes: Select the desired characteristic variables:
a > OK.
Characteristic variable is switched on:
A maximum of 6 characteristic variables can be displayed in the
Measurement view Statistics, description of characteristic variables,
15.
b Continue with step 3.
• No: Continue with step 3.
3. Exit the menu: , the settings are now made.
The measured readings (and statistical evaluations) are displayed according to the
newly set Measurement view.
12.4 Selecting characteristic variables for the statistical displays
For the open batch, you can select the statistical characteristic variables that are to
be displayed on the evaluation pages Batch Statistics and Block Statistics.
Before you start
 The batch for which you want to make the changes is open in the gauge.
To select the statistical characteristic variables
1. > Batch Modify > OK > Views Settings > OK > Batch Statistics View or Block
Statistics View > OK
2. Select the desired characteristic variables: > OK.
Characteristic variable is activated:
Description of the characteristic variables, 15
3. Exit the menu: , the settings are now made.
[ ]
