DMP30 / DMP40 Settings for measurement
7 Settings for measurement
In order to measure, you need to create and open a batch (measuring file). Settings,
such as those for the measurement procedure are saved in the batch, e.g. specifica-
tion limit monitoring and grouping of measured readings in measurement blocks
during the measurement and in measuring mode. The link to the calibration to which
the measurements are referenced is also stored in the batch file.
If any parameter changes, there is a new measuring application and you have to cre-
ate a new batch.
A description of the possible batch settings you have to make befo re a mea-
surement can be found below.
A description of the batch settings, which you can also make after a mea-
surement, can be found from page 82.
7.1 Creating a new batch
You can create a batch in the following ways:
Create a new batch from scratch
In this case, you must make all the required measurement settings again.
1. > Batches >
OK >
New > Select a calibration from the list or New from >
OK
2. Have you selected a calibration from the list?
• No: Continue with step 3.
• Yes: Continue with step 4.
3. Follow the calibration routine and finish each calibration step via OK. You can also
skip the last calibration step (Std. 2) via , 62.
4. Make the desired batch settings for the measurement 38, assign a batch
name, 88
This completes the creation process for a new batch.
5. Call up the Measurement view for the new batch: MEASURE > OK.
[ ]
