67
DMP30 / DMP40
Calibration
9.9 Calibration - assigning/changing names
Assign a unique name to the calibration (calibration method, material designation,
batch no., …), example: Z+1F EN AW 6082 or Z EN AW 6082.
Keep in mind that many calibrations involving different calibration methods for
different base materials can be stored in the probe/DMP-F probe adapter. A
unique name makes it easier to select and assign the desired calibration to a
batch.
Before you start
The probe is connected to the gauge (via DMP-F probe adapter) containing the
calibration whose name you want to change.
If the calibration whose name you want to change is locked, you need to know
the lock code.
To change the name of a calibration
1. Select the calibration whose name you want to change: > Calibrations > OK >
select name of calibration > OK.
2. Prompted to set the lock code?
• Yes: Set the lock code and deactivate the lock function, 73.
Function is deactivated:
• No: Continue with step 3.
3. Open the input menu: Rename > OK.
4. Change the name:
• Move cursor using the and OK keys
• Select characters using the and OK keys
• Delete characters by selecting the space ( )
5. Exit the input menu:
a Move the cursor to the far right using the OK key. The character appears
at the right edge of the display.
b Press OK to close the input menu.
[ ]
