Description DMP30 / DMP40
V[%] Coefficient of variation, percentage variation of a series of measurements,
standard deviation in terms of the mean value , a sudden change in the
coefficient of variation indicates a change in process conditions
n<USL Number of measured readings per block or batch below the lower specifi-
cation limit
n>OGW Number of measured readings per block or batch above the upper specifi-
cation limit
Characteristic variables occurring during the control measurement for check-
ing a selected calibration: a description of the characteristic variables can be
found on page 69
3.7 Menus – function overview
Menu Statistics
View of the statistics for the open batch
Batch Modify menu
Settings and entries for the open batch
 Batch Modify > MEASURE
Opens the Measurement view, starts the measurement with the probe posi-
tioned on the specimen surface
 Batch Modify > Limits
Activates limit monitoring and sets the specification limits
 Batch Modify > Batch Info
Information on the measurement and batch settings
 Batch Modify > Views Settings
• Measurement view: selects the display
• Batch statistical display: selects the statistical characteristic variables to be
displayed
• Block statistical display: selects the statistical characteristic variables to be
displayed
