Set-up Mode
Where used
Mach 500 · Mach 300 · Mach 200
Summary
When the machine is in Set-up Mode, you can interrupt the light curtain beam without causing an E-
stop condition, jog the axes manually within the preset speed limits, and turn the water and abrasive
on or off in FlowCUT. Once the machine is in Set-up Mode, the indicators on the roll-around
console continually flash red and white and the pump is in an E-stop condition.
To put the machine in Set-up Mode
To put the machine in Set-up Mode, do the following:
1. Put the machine in Manual state (drives are enabled and you can jog the axes manually).
You must put the machine in Manual state before you turn the key switch to ON.
Otherwise, it will cause a machine E-stop condition and you'll get a System: Safety Device/
Light curtain (M934) FlowSENSE error. Pushing the Reset button will not fix the error.
2. On the roll-around console, turn the Set-up Mode key to ON.
To recover from Set-up Mode error
To recover from a Set-up Mode error, follow these steps:
1. Select Option Component, and then select Reset Ethercat (After reset, Cycle E-stop/
Reset/Power Buttons).
2. Press and release the E-stop, and then press the Reset button.
