Vital Signs Simulator
ECG Function
13
To change the ECG waveform:
1. Push or to move the highlight to the Wave Group value.
2. Push .
3. Push or to move the highlight to a waveform group name. Table 8 is a
list of the wave groups available in the Product.
Table 8. ECG Wave Groups
Wave Group
NSR (Adult) Adult Normal Sinus Rhythm
NSR (Pediatric) Child Normal Sinus Rhythm
Performance
Special waveforms for monitor tests. See ECG
Performance Tests.
R-Wave Detection
QRS Detection
Tall T Wave Rejection
Supraventricular
Arrhythmia waveforms. See Simulate Arrhythmias.
Premature
Ventricular
Conduction
TV Paced
ACLS
4. When the Waveform Group value is highlighted, push .
To change the heart rate:
1. Push or to move the highlight on the display to the Heart Rate value.
2. Push .
3. Push or to adjust the heart rate. Each push of a key moves the heart
rate one beat in the direction of the key pushed. The Product simulates a
heart rate of 10 to 360 beats/minute (BPM) set in 1 BPM intervals.
4. Push to set the heart rate and go back to the ECG screen.
To change the axis:
1. Push or to move the highlight to the Axis value.
2. Push .
3. Push or to highlight Intermediate, Horizontal, or Vertical.
4. Push .
