ProSim 8
Users Manual
14
To set the ST Deviation:
1. Push  or  to move the highlight to the ST Deviation value.
2. Push .
3. Push  or  to adjust the deviation. Each push of a key moves the deviation
0.05 or 0.1 mV in the direction of the key pushed. The deviation range is
±0.80 mV
Note
When the ST Deviation value is set to 0.00 mV, the value in the ECG
screen shows as Off.
4. Push  to set the deviation and go back to the ECG screen.
To set the ECG signal amplitude:
1. Push  or  to move the highlight on the display to the Amplitude value.
2. Push .
3. Push  or  to adjust the amplitude. Each push of a key increases or
decreases the amplitude 0.05 mV between 0.05 mV and 0.50 mV and
0.25 mV above 0.50 mV to 5.00 mV in the direction of the key pushed.
4. Push  to set the signal amplitude and go back to the ECG screen.
Table 9 shows the percentage of the signal amplitude value that is put on each
ECG lead.
Table 9. ECG Lead Amplitudes
Waveform I II III V1 V2 V3 V4 V5 V6
Performance
[1]
70 % 100 % 30 % 100 % 100 % 100 % 100 % 100 % 100 %
Normal Sinus 70 % 100 % 30 % 24 % 48 % 100 % 120 % 112 % 80 %
Normal Sinus,
Horizontal Axis
100 % 30 % -70 % 20 % 40 % 70 % 100 % 80 % 50 %
Normal Sinus,
Vertical Axis
30 % 130 % 100 % 20 % 30 % 40 % 60 % 80 % 100 %
[1] Includes R-Wave Detection, QRS Detection, and Tall T-Wave Rejection waves.
