Vital Signs Simulator
Non-Invasive Blood Pressure Simulation and Tests
47
Figure 30 shows the blood pressure cuff mandrel sizes.
Large Adult
Adult
Cap
Cap
Small Adult
Child
Small Child
Neonatal
fcv011.eps
Figure 30. Blood Pressure Cuff Mandrel Sizes
To set the blood pressure simulation, push to show the NIBP screen in
Figure 31 on the display.
Figure 31. Non-Invasive Blood Pressure Screen
