Alerts Output
FortiAnalyzer Version 3.0 MR3 Administration Guide
05-30003-0082-20060925 135
Figure 66: Syslog server list
Adding a Syslog server
To add a new Syslog server
1 Go to Alert > Output > Syslog Server.
2 Select Create New.
3 Configure the following options, and select OK.
FortiAnalyzer SNMP support
You can configure the FortiAnalyzer unit to report system information and send
traps (alarms or event messages) to SNMP managers. Using an SNMP manager,
you can access SNMP traps and data from the FortiAnalyzer unit.
The FortiAnalyzer SNMP implementation is read-only. SNMP v1 and v2c
compliant SNMP managers have read-only access to FortiAnalyzer system
information and can receive FortiAnalyzer traps. To monitor FortiAnalyzer system
information and receive FortiAnalyzer traps you must compile Fortinet proprietary
MIBs as well as Fortinet-supported standard MIBs into your SNMP manager.
RFC support includes support for most of RFC 2665 (Ethernet-like MIB) and most
of RFC 1213 (MIB II)
The FortiAnalyzer unit uses the FortiGate MIB for object identifiers. You can
obtain the MIB files from Fortinet technical support. To be able to communicate
with the SNMP agent, you must compile all of these MIBs into your SNMP
manager.
Create New Select to add a new Syslog server.
Name The name given to the Syslog server.
IP or FQDN: Port The IP address or fully qualified domain name for the SNMP
server, and port number.
Action Select Delete to remove the Syslog server configuration.
Select Edit to change the Syslog server configuration.
Select Test to verify the Syslog server configuration.
Delete
Edit
Test
Name Enter a name for the SNMP server.
IP address (or FQDN) Enter the IP address or fully qualified domain name for the SNMP
server.
Port Enter the Syslog server port number. The default Syslog port is
514.
