Fronius FPA 3020 Orbital - Display During Upslope; Display During Welding; Display During Downslope; Display During Gas Post-Flow

34
- Number appearing next to
„START, UPSLO“ is the time elapsed
since welding started
- Seg 1
status indicator for current segment
- Pos
position of the orbital welding gun [°]
- Spd
welding speed [cm/min]
- Cur
welding current [A]
- Volt
welding voltage [V]
- Number appearing next to
„WELDING“ is the time elapsed since
welding started
- Seg 1
status indicator for current segment
- Pos
position of the orbital welding gun [°]
- Spd
welding speed [cm/min]
- Cur
welding current [A]
- Volt
welding voltage [V]
- Number appearing next to
„DOWNSLOPE“ is the time elapsed
since welding started
- Seg 1
status indicator for current segment
- Pos
position of the orbital welding gun [°]
- Spd
welding speed [cm/min]
- Cur
welding current [A]
- Volt
welding voltage [V]
- Number appearing next to
„GAS POSTFL“ is the time elapsed
since welding started
- Seg 1
status indicator for current segment
- Pos
position of the orbital welding gun [°]
- Spd
welding speed [cm/min]
- Cur
welding current [A]
- Volt
welding voltage [V]
Display during
upslope
Display during
welding
Display during
downslope
Display during
gas post-ow
Pos/D
Speed
Curr
Volt
0
0.0
0
0.0
Seg 1
cm/min
A
V
START, UPSLO 3.0
Pos/D
Speed
Curr
Volt
0
0.0
0
0.0
Seg 1
cm/min
A
V
WELDING 12.0
Pos/D
Speed
Curr
Volt
0
0.0
0
0.0
Seg 1
cm/min
A
V
DOWNSLOPE 3.0
Pos/D
Speed
Curr
Volt
0
0.0
0
0.0
Seg 1
cm/min
A
V
GAS-POSTFLOW 6.0
