Technical Data
For devices designed for special voltages, the technical data on the rating plate applies.Special voltages
Power source
Rated supply voltage (U1) 1x 230 V
Maximum effective primary current (I1eff) 13.2 A
Maximum primary current (I1max) 22.2 A
Mains fuse protection 16 A slow-bow
Supply voltage tolerance - 10 / +15 %
Supply voltage frequency 50 / 60 Hz
Cos phi (1) 0.99
Recommended type of RCD B
Welding current range (I2)
TIG
5 – 200 A
Welding current at 10 min / 40°C (104°F)
U1 230 V
35 % 60 % 100 %
200 A 145 A 110 A
Output voltage acc. Standard (U2)
TIG
10.2 – 18.0 V
Rated no-load voltage (U0 peak / r.m.s.) 44 V
Reduced rated no-load voltage (Ur) not applicable
Rated peak voltage (Up) 9.5 kV
Degree of protection IP 23
Type of cooling AF
Overvoltage category III
Pollution degree according IEC 60664 3
EMC emission class A
Marks of conformity S, CE
Dimensions L x W x H 650 x 290 x 480 mm
25.6 x 11.4 x 18.9 in
Weight 38 kg
84 lb
Coolant Original Fronius
Sound power level (LWA) ---
