116
Network menu item
Cluster network A cluster network allows you to create a local network within several Virtual Welding sys-
tems. This makes it possible to control the entire course management of the Virtual Weld-
ing systems from one master device.
Connect all the Virtual Welding systems with a commercially available router (make
sure that TCP port 778 is not blocked) and follow these instructions:
On the menu, touch the "Cluster" but-
ton
in the cluster menu you can configure the system either as a master or as one of the slaves.
In the following we first explain how to configure as the master and then how to configure
as a slave.
SlaveSlave
Router
Master
1
2
