Fuji Electric Micro-Controller X Socket type User Manual

43
2nd block parameter
P-SL
Lower limit of measuring range (044)
P-SU
Upper limit of measuring range (045)
[Description] –––––––––––––––––––––––––––––––––––––––––––––––––––––––
PV input
1200℃
0℃
1000℃
200℃
Scaling range
upper/lower limit
Allows you to set the upper/lower limit of PV input within the
measurement range.
Setting range
-1999 to 9999

Be sure to set the values so that [P-SU] is greater than [P-SL].

Be sure to set the values so that the subtraction of [P-SL] from [P-SU] is less than
10000 with no decimal point.

Measurement range
Input type
[P-N2]
Setpoint
Measurement
range
Minimum
increment
(°C)
RTD JPt100
JPt
0.0 to 150.0
0.1
0.0 to 300.0
0.1
0.0 to 500.0
0.1
0.0 to 600.0
0.1
-50.0 to 100.0
0.1
-100.0 to 200.0
0.1
-199.9 to 600.0
0.1
RTD Pt100
Pt
0.0 to 150.0
0.1
0.0 to 300.0
0.1
0.0 to 500.0
0.1
0.0 to 600.0
0.1
-50.0 to 100.0
0.1
-100.0 to 200.0
0.1
-199.9 to 600.0
0.1
-200 to 850.0
1
Thermocouple J
J
0.0 to 400.0
0.1
-20.0 to 400.0
0.1
0.0 to 800.0
0.1
-100 to 1000
1
Thermocouple K
K
0 to 400
0.1
-20.0 to 500.0
0.1
0.0 to 800.0
0.1
-200 to 1300
1
Thermocouple R
R 0 to 1700
1
Thermocouple B
b 0 to 1800
1
Input type
[P-N2]
Setpoint
Measurement
range
Minimum
increment
(°C)
Thermocouple S
S 0 to 1700
1
Thermocouple T
t
-199.9 to 200.0
0.1
-199.9 to 400.0
0.1
Thermocouple E
E
0.0 to 800.0
0.1
-150.0 to 800.0
0.1
-200 to 800
1
Thermocouple L
L -100 to 850
1
Thermocouple N
N -200 to 1300
1
Thermocouple
PL-II
PL-2 0 to 1300
1
Thermocouple W
W 0 to 2300
1
DC voltage
DC0 to 5V
0-5V
-1999 to 9999
(Scaling is
possible)
―
DC voltage
DC1 to 5V
1-5V
DC voltage
DC0 to 10V
0-10
DC voltage
DC2 to 10V
2-10
Direct current
0-20mA
0-20
Direct current
4-20mA
4-20
Thermocouple U
U
-199.9 to 400.0
0.1
-200 to 400
1
