Fuji Electric Micro-Controller X Socket type User Manual

18
Basic Operation
3rd block parameter
No Display
Parameter
symbol
Parameter name Setting range
Factory
default setting
Parameter
mask DSP
Reference
page
90 P-N1 Control action 0 to 3 0 DSP9-16 57
91 SV-L SV (Set value) lower limiter 0 to 100%FS 0 (°C) DSP9-32
58
92 SV-H SV (Set value) upper limiter 0 to 100%FS 400 (°C) DSP9-64
93 dLY1 Delay time 1 0 to 9999 (sec) 0 DSP9-128
59
94 dLY2 Delay time 2 0 to 9999 (sec) 0 DSP10-1
98 A1Hy Alarm 1 hysteresis 0 to 50%FS 1 (°C) DSP10-16
59
99 A2Hy Alarm 2 hysteresis 0 to 50%FS 1 (°C) DSP10-32
101 A1oP Alarm 1 options 000 to 111 000 DSP10-128
61
102 A2oP Alarm 2 options 000 to 111 000 DSP11-1
104 PLC1 Lower limit for output 1 -5.0 to 105.0 (%) -5.0 DSP11-4
62
105 PHC1 Upper limit for output 1 -5.0 to 105.0 (%) 105.0 DSP11-8
108 PCUt Output limit types 0 to 3 0 DSP11-64 63
109 oUt1 Output value (MV) display ― ― DSP11-128 64
111 RCJ
RCJ (Cold junction
compensation) setting
oN, oFF oN DSP12-2 65
112 GAiN PV gradient 0.001 to 2.000 1.000 DSP12-4 ―
113 AdJ0
User-denable zero
adjustment
-50 to 50%FS 0 (°C) DSP12-8
66
114 AdJS
User-denable span
adjustment
-50 to 50%FS 0 (°C) DSP12-16
126 dSP1
Parameter mask ―
Depends on
the model
DSP14-128 68
127 dSP2
…
138 dP13
139 dP14
143 UKy1 USER key 0 to 6 0 DSP14-8
70 144 UKy2 USER key + UP key 0 to 6 1 DSP14-16
145 UKy3 USER key + DOWN key 0 to 6 5 DSP14-32
146 FLo1 MV1 during FALT -5.0 to 105.0 (%) -5.0 DSP14-64 71
148 dSPt PV/SV display OFF 0 to 8 0 DSP14-256 72
