Basic Operation
2nd block parameter
No Display
Parameter
symbol
Parameter name Setting range
Factory
default setting
Parameter
mask DSP
Reference
page
30 P Proportional band 0.0 to 999.0 (%) 5.0 DSP3-2
30
31 i Integral time 0 to 3200 (sec) 240 DSP3-4
32 d Derivative time 0.0 to 999.9 (sec) 60.0 DSP3-8
33 HyS
Hysteresis range for ON/
OFF control
0 to 50%FS 1 (°C) DSP3-16
32
36 bAL Output convergence value -100.0 to 100.0 (%) 0.0 DSP3-128
34
37 AR Anti-reset windup 0 to 100%FS 400 (°C) DSP4-1
35
38 CtRL Control algorithm
oNoF, Pid, FUZY, SELF, Pid2
Pid DSP4-2
36
39 SLFb
PV (Process variable) stable
range
0 to 100%FS 8 (°C) DSP4-4
39
40 oNoF Hysteresis mode oN, oFF oN DSP4-8
40
41 tC
Cycle time of control output 1
1 to 150 (sec)
Relay: 30
DSP4-16
41
SSR: 2
Current: 1
43 P-N2 Input signal code
JPt (Resistance bulb (RTD) JPt100)
Pt (Resistance bulb (RTD) Pt100)
J (Thermocouple J)
K (Thermocouple K)
R (Thermocouple R)
b (Thermocouple B)
S (Thermocouple S)
t (Thermocouple T)
E (Thermocouple E)
L (Thermocouple L)
N (Thermocouple N)
PL-2 (Thermocouple PL-II)
W (Thermocouple W)
0-5V (DC voltage 0 to 5V DC)
1-5V (DC voltage 1 to 5V DC)
0-10 (DC voltage 0 to 10V DC)
2-10 (DC voltage 2 to 10V DC)
0-20 (Direct current 0 to 20mA)
4-20 (Direct current 4 to 20mA)
U (Thermocouple U)
MV (MV)
K DSP4-64
42
44 P-SL
Lower limit of measuring
range
-1999 to 9999 0 (°C) DSP4-128
43
45 P-SU
Upper limit of measuring
range
-1999 to 9999 400 (°C) DSP5-1
46 P-dP Decimal point position 0 to 3 0 DSP5-2
45
48 PVOF PV offset -10.00 to 10.00%FS 0 (°C) DSP5-8
46
49 SVOF SV shift -50.00 to 50.00%FS 0 (°C) DSP5-16
47
50 P-dF Time constant of input lter 0.0 to 120.0 (sec) 5.0 DSP5-32
48
51 ALM1 Alarm type 1 0 to 31 0 DSP5-64
49
52 ALM2 Alarm type 2 0 to 31 0 DSP5-128
54 StAt Status display of ramp soak ― ― DSP6-2
51
55 PtN
Ramp soak execution pattern
1 to 3 1 DSP6-4
52
