174
8 Maintenance
3. Pinch and hold the knob on both sides of the conveyance box and remove the box.
Note
Stand the box upright on a level surface.
4. Turn the stopper of the drum cartridge (R1, R2, R3, R4) displayed in the message to the right.
The illustrations in this section explains how to replace the drum cartridge R2, as an example.
5. Press the tab to release the lock.
To Next Page
