Fuji Xerox ApeosPort Print C5570 User Manual

185
8.1 Replacing Consumables
3. While grasping the levers of the booklet staple cartridge, push downward, and then pull out upwards.
Note

There are two booklet maker staple cartridges. Confirm the cartridge has been replaced from the message.
4. Press the buttons on the right and left sides of the booklet staple cartridge (1), and then open the cover (2).
5. Pinch the right and left sides of the empty staple case (1), and pull out the empty staple case from the staple
cartridge (2).
Important

The staple case cannot be removed when the staples are remained in the staple case. Forcibly removing the staple case
may cause device malfunction.
6. Insert the new staple case (1), and push the rear side of the new staple case into the booklet staple cartridge
(2).
(1)
(1)
(2)
(1)
(1)
(2)
(1)
(2)
