5.5 Replacing Consumables
140
Maintenance
5
●
Do not place the new drum cartridge in an upright
position.
●
Return used toner cartridges to our Customer Sup-
port Center for disposal.
7
Place the new drum cartridge (with pro-
tective cover) on the handle, and insert
the end of the drum cartridge into the
machine.
Insert the drum cartridge up to the arrow mark as shown
in the figure on the right.
8
Peel off the seal from the top of the
drum cartridge while the end of the car-
tridge is inserted in the machine.
9
Press down on the front part of the pro-
tective cover ((1)) and use the orange
tab at the top to slide the cartridge for-
ward while inserting the drum cartridge
as far as possible while keeping it
straight((2)).
Place the protective cover as is into the box.
10
Lift up the handle to return it to its origi-
nal position.
