Installation Specifications
364
Installation Specifications
The following table summarizes the installation specifications of the ScanSnap.
Item Specifications
Dimensions
(Width × Depth × Height)
Minimum: 292 × 159 × 158 mm
(approx. 11.5 × 6.3 × 6.2 [in])
Maximum: 292 × 475 × 286 mm
(approx. 11.5 × 18.7 × 11.3 [in])
Weight 3.0 kg (approx. 6.62 lb)
Input power
supply
Voltage 100 to 240 V (varies regionally)
Number of
phases
Single-phase
Frequency 50/60 Hz
Power consumption During operation: 35 W or less
During standby: 4.5 W or less
Temperature/
humidity
allowable
ranges
Temperature During operation: 5 to 35 (°C) / 41 to 95 (°F)
During standby: -20 to 60 (°C) / -4 to 160 (°F)
During storage/transportation:
-20 to 60 (°C) / -4 to 140 (°F)
Humidity (%) During operation: 20 to 80
During standby: 8 to 95
During storage/transportation: 8 to 95
292 mm (11.5 [in]) 475 mm (18.7 [in])
286 mm
(11.3 [in])
