FUTABA 7XC - Gyro Mixing

Home screen
Menu screen
Menu-2
Menu-1
Mixing menu
Gyro mixing
108
Function
Gyro Mixing
This function is a remote gain function which adjusts the sensitivity of the Futaba car rate
gyro at the T7XC side, and is mixing that uses the auxiliary channels to adjust the gyro sen
-
sitivity. When using the T7XC by switching the AVCS and normal modes use SW1 to SW6
with the
"
Switch select
"
function (page 67).
For a description of the car rate gyro mounting method and handling, refer to the rate gyro
instruction manual.
Gyro Mixing
When using SR mode compatible gyro in SR mode channel, set both steering input and
gyro sensitivity input channel to SR mode. If either one is in normal mode, gyro will not
operate properly.
The gyro has 2 operating modes: NORMAL mode and AVCS mode. In the AVCS mode,
the angle is controlled simultaneously with NORMAL mode rate control (swing speed).
The AVCS mode increases straight running stability more than that of the NORMAL
mode. Because the feel of operation is different, choose your favorite mode.
AVCS / NORMAL Modes
The mixing function is assigned to auxiliary channels used by other mixing cannot be
used. When the number of channels is insufcient, cancel the other mixing.
