Home screen
Menu screen
Menu-2
Menu-1
Linkage menu
Channel limiter
For S-FHSS (analog) system,
channels 5, 6 and 7 are displayed
on the 2nd page.
Tap to change page.
72
Function
Channel Limiter
Channel Limiter
The channel limiter function limits maximum servo movement. By superimposing mixing,
the linkage can be protected by setting the limiter in case servo motion becomes unexpect-
edly large.
(Preparation)
- Tap the travel button of the channel you want to set. Value in-
put buttons appear on the screen.
1
Use the [+] or [-] buttons to adjust the servo
angle.
Channel limiter adjustment
2
When fi nished, return to the Linkage menu screen by pressing the HOME button.
Adjust button
Adjust with the [+] and [-] but-
tons.
- Return to the initial value by
tapping the [reset] buttons.
Limiter rate
0~145
Initial value: 145
To Next Page
