Communication port.
Connecting ESC receiver
connector to the transmitter
Communication port.
Battery
139
Function
MC (ESC) Link
Home screen
Menu screen Accessory menu screen
MC (ESC) Link
This is a special function which allows Futaba motor controller (MC) data changes to be set
by the T7XC transmitter (MC960CR, MC950CR, MC851C, MC602C, MC402CR, etc.).
However, some data changes require a PC and Link software.
This function is used by connecting ESC directly to the transmitter.
Use the various optional servo extension cords according to the distance between the trans-
mitter and ESC.
MC (ESC) Link
-Also connect the battery at the ESC side.
Setup item (after it reads)
Read
Write
Reset
Data list
