FUTABA 7XC - Specialized Mixing and Control

When the mode is activated by a switch, indicated
on the home screen for a few seconds.
Home screen
Menu screen
Menu-2
Menu-1
Mixing menu
4WS mixing
Display the current 4WS type.
111
Function
4WS Mixing
4WS Mixing
This function can be used with crawlers and other 4WS type vehicles. It is mixing that uses
the 1st channel to control front side steering and the auxiliary channel to control rear side
steering.
A method of specifying directly for each type of opposite phase (only on the in-phase side),
reverse phase, in-phase side and rear side by selecting SW1, SW2, SW4, SW5 and SW6 in
the
"
Switch select
"
function (page 67). And, it is possible to switch in order.
The mixing function is assigned to auxiliary channels used by other mixing cannot be
used. When the number of channels is insuf cient, cancel the other mixing.
(Preparation)
- Since this function is used by switching the type of 4WS with a switch, the switch used by the
"Switch select" function (page 67) is set.
4WS mixing adjustment
1
(Function ON/OFF)
Tap "Mixing" (ON) or (OFF) to select ON /
OFF.
"OFF" :Mixing function OFF
"ON" :Mixing function ON
Setting
- Tap (ON) / (OFF).
