Calibration
Home screen
Menu screen
System menu screen
Menu-2
Menu-1
183
Function
Calibration
Steering and throttle correction can be applied. Use this function when a mechanical offset
has occurred for some reason.
Calibration
However, if correction was applied, it may be necessary to recheck the set values of all
the setup functions.
(Preparation)
Tap the [Wheel]. The neutral correction screen appears.
1
(Steering neutral adjustment)
At neutral, turn the steering stick left and right. Tap the [Neu-
tral] button while the steering stick is in its neutral position. If
the [Neutral] position is OK, the [End Point] button will appear
after tapping the [Neutral] button. If not within the correction
range, the [End Point] button will not appear.
2
(Steering stick travel adjustment)
With [End Point], slowly rotate the steering stick left and right,
tap the [End Point] button. If the [End Point] correction is OK,
the display will return to the calibration screen. If the end point
is not within the correction range, the display does not return
to the adjuster screen. In this case, return to the system menu
screen by pressing the HOME button. If operation cannot be
ended normally even when correction is repeated, please con-
tact the Futaba Service Center.
Steering adjustment
3
When finished, return to the System menu screen by pressing the HOME button.
